JST SPH-002T-P0.5S
Features
-Materials: Contacts are often made from phosphor bronze with tin or gold plating, providing good conductivity, durability, and resistance to corrosion.
-Keying: Designed with polarization features such as keying slots or tabs to prevent incorrect insertion and ensure proper orientation of the connector.
-Termination Options: Supports various wire termination methods including crimping, soldering, and IDC (Insulation Displacement Contact), offering flexibility in assembly processes.
-Operating Conditions: Typically rated for a wide range of operating temperatures (often between -25°C to +85°C or higher), ensuring reliable performance in various environmental conditions.
Applications
1.Industrial Equipment
2.Automotive Electronics
3.Medical Devices
4.Consumer Goods
Specifications
Electrical Specification:
Rated Voltage: 125V AC.DC
Rated Current: 2A
Contact Resistance: 0.02 Ohm max
Insulation Resistance: 1000M Ohm min
Withstand voltage: 800V AC/MIN
Temperature range for usage : -40ºC~+105ºC
P.C board thickness : 0.8~1.6mm
Material:
Housing: PA66 UL94V-2
Contacts: Phosphor Bronze or Brass
Plating: Tin 50u" over 100u" nickel
Wire range : AWG#32~#22
Technical Documents
Please contact us for more information.
JST SPH-002T-P0.5S 2.00mm JST PH type Wire to Board Connector:RHTAYL1-2.00
