Features
-Number of Pins: Available configurations include 15P, 26P, 44P, and 62P (refers to the number of signal pins)
-Termination Type: Simple Solder Type, designed for soldering directly to PCB pads for a secure and reliable connection.
-Material: Often constructed from metal (e.g., steel, brass) for durability and good electrical conductivity.
-Shielding: Provides electromagnetic interference (EMI) shielding, crucial for applications requiring noise reduction and signal integrity.
Applications
1.Medical Devices
2.Test and Measurement Instruments
3.Military and Aerospace Applications
4.Automotive Electronics
Specifications
HDB 3 Row D-SUB Connector,Simple Solder Type,15P 26P 44P 62p Male Female
Order Information
RHTAYB14-XX-M-L
XX-No.of 15,26,44,62pins
M-Male F-Female
L-Blue B-Black W-White
Material:
Housing: PBT+30% Glass filled ,UL94V-0
Contacts: Brass , Gold Plating on Contact Arer, Tin on Solder Tail.
Shell: Steel, Front Shell Nickel Plating, Back Shell Tin Plating
Electrical Characteristics:
Current Rating: 5 AMP
Insulator Resistance: 1000MΩ Min. at DC 500V
Withstanding Voltage: 500V AC (rms) for 1 minute
Contact Resistance: 20mΩ Max. Initial
Operating Temperature: -55°C~+105°C
Technical Documents
Please contact us for more information.
